3499F

Popular Drain/Pipe Inspection Camera System with 20m/66ft ~ 40m/130ft cable
This is a professional video inspection camera designed for inspection of sewer, pipe, air ducts, underground cable pipes, etc.. Equipped with a 1080P AHD 23mm camera head, 20-40m fiberglass cable and 7'' or 10'' LCD monitor with SD card recording, it's a great choice for pipe DN 30MM - 150MM.
Key Features:


  • Unique, professional and compact design.
  • 1/3 inch CMOS, 130° wide vision angle
  • 1080P Full HD Stainless steel camera head, IP68 waterproof level
  • Sapphire glass lens cover, 15 high light white LEDs
  • Diameter of camera: 23 mm
  • Two plastic guides for camera head, Φ46mm & 80mm
  • 7” or 10'' LCD color monitor, with image rotate button
  • SD Card slot to store still pictures or videos
  • One push record button
  • LED brightness control buttons
  • With microphone for local audio recording
  • Rechargeable battery lasts up to 6 hours
  • On-Screen date and time
  • 20, 30 or 40m fiberglass φ5.2mm push rod
  • The cable reel is out of the box, easy to clean and won’t cause dirty in the box.
  • Ability to go through 90°bends in Φ45mm pipes
  • With smart braking system
  • With on-screen distance counter
  • With Keyboard for text input (English)
  • Whole system waterproof (box closed)

Optional Features:
  • Built-in 512hz sonde
  • Self-leveling function
  • 33khz transmitter
  • 10.1" LCD screen
  • 38mm camera head
Specification:

Camera Head
  • Camera Size: Φ23mm×51mm
  • Camera Total Length: 155mm
  • Sensor: 1/3" CMOS
  • Resolution: AHD 1920*1080
  • View Angle: 130°
  • Focus Distance: 15cm (approx)
  • Depth-of-Field: 20cm(approx)
  • Front Lens: Sapphire glass
  • Water-Proof: 20m Under Water(Camera fix on Cable)
  • Shell Material: #304 stainless steel
  • Lighting: Built-in 15×LED(White)
  • Operating Temperature: -10~50℃/+14~+122℉
  • Storage Temperature: -20~60℃/+4~+140℉

Cable Wheel
  • 20/30/40M fiberglass rod cable
  • Dia. of push cable: 5.2mm
  • Material of cable: Fiberglass covered by PP

LCD Monitor
  • Screen: 7-inch or 10-inch 16:9 Super bright HD color LCD screen
  • Resolution: 1024x600 pixels
  • Mirror and Flip: support image mirror, and flip
  • Video Resolution: AHD 1080P / CVBS D1
  • Video Encoding: H.264
  • Audio Recording: local sound record
  • Output: TV and Audio output
  • On-screen date and time
  • On-screen meter/ft. distance display(optional)
  • External memory: support SD memory card up to 64GB
  • Language: Simplified Chinese, English, Traditional Chinese, Japanese, Korean, Russian, German, French, Italian, Spanish, Portuguese, Thai, Finnish, Swedish

Battery Supply
  • Power Supply: DC 12V input
  • Battery Capacity: 7.2V 6400mAh Li-on Battery
  • Power Output: 6-12V DC, USB 5V
  • Work/Charge time: 6/8 hours

What's Included:
  • 1 x 23mm Camera head
  • 1 x 20/30/40m cable wheel
  • 2 x Plastic guides(dia.80mm and dia.46mm)
  • 1 x remote control
  • 1 x screw driver
  • 1 x power adapter
  • 1 x car charger
  • 1 x connection cable
  • 1 x Screws and camera head waterproof seal
  • 1 x waterproof control box with monitor mounted
